The IM150 Wireless Light and Color Meter uses Bluetooth technology to deliver the correct exposure and color temperature for any type of light – even flash – directly to your smartphone! The IM150  meter has all the functions of other meters, plus the convenience of remote sensing & multiple sensors in a very small and light package. And all this for less than the cost of an inexpensive lens. Whether you are creating still or moving images, the IM150 meter is the right tool for all conditions. Join the Illuminati and gain mastery of light.

What’s included:

  • IM150 Wireless light & color meter
  • Two “AA” alkaline batteries
  • Hardshell storage case
  • Offset-T magnetic mounting clip
  • Alligator magnetic mounting clip
  • Quick-start guide
  • Wirelessly connect one or many Illuminati meters to your smartphone and measure any kind of light from anywhere
  • Measure ambient, continuous, and strobe lighting at multiple locations in a scene
  • Set lighting ratios accurately and without leaving your lights
  • Color match continuous lights/strobes to ambient or any color temp
  • Mount meters on every rented light to measure and tame color
  • Improve your productivity while setting up lights and also while processing your images later
Supported Operating Systems Apple devices running iOS8.1 or higher
Android devices running 4.3 or higher
Connectivity Bluetooth 4.0 (BLE)
Exposure Measuring Range 1.0 to 1,000,000 lux (-1 EV to 18 EV)
Color Temperature Range 1,600 K to 20,000 K
Setting Ranges ISO: 3 to 409,600
Shutter Speed: 1/64,000 to 30 sec
Aperture: f/0.5 to f/144
Shutter Angle: 1 to 358
Frame Rate: 1 to 1000 fps
Metering Modes Ambient – manual or continuous monitoring
Flash with sync cord
Cordless flash with pre-flash rejection
Flash Sync Connector 3.5 mm (1/8”) jack
Operating Range Up to 80 ft (24 m). Actual range will vary
Batteries Two AAA (UM4)
Dimensions 3.0” x 2.8” x 0.9” (78 x 70 x 22 mm ), W x D x H,
excluding dome. With dome, 1.2” (30 mm) high
Weight 1.4 oz (38 g) without batteries
2.2 oz (62 g) with batteries
IM100/IM150 Quickstart Guide
Guide to getting up and running quickly.
IKM100/IM150 User Manual for iOS 2.4
Current version of the user manual for iOS devices.
IKM100/IM150 User Manual for Android 1.41
Current version of the user manual for Android devices.

There are no drivers or downloads at the moment.

Feature Highlights

Measure Continuous Lighting

  • Exposure: Shutter Speed, Aperture, ISO, plus Frame Rate & Shutter Angle for video
  • Color Temperature: Kelvin
  • Measures all kinds of continuous light, including LED, HMI, tungsten, fluorescent and daylight

Measure Strobes

  • Combines both exposure and color temperature for strobe readings
  • Dedicated high-speed circuitry to filter out camera pre-flash and accurately measure strobe power & color
  • Measure strobe ratios (foreground/background or main/fill/hair, etc.)
  • Helps you detect and correct color differences under mixed lighting, or craft deliberate neutral + warm/cool lighting scenarios

Strobe + Ambient Exposure with matched color © Tony Corbell

Measures Color of Strobe & Ambient

  • Detect and correct color differences when shooting with mixed lighting
  • Select gels for correcting your strobe or LED lights
  • Libraries for Rosco and Lee filters

Connect Multiple Meters to your Phone

  • Simultaneously measure color of different light sources, e.g. daylight from windows and artificial lighting
  • Meter large areas to get uniform lighting – great for green screens
  • Measure the foreground and background simultaneously with multiple meters
  • Measure strobe ratios (foreground/background or main/fill/hair, etc.)

Color Temperature in App

Chromaticity Measurements in App

Measure Illuminance in Lux & Color in Chromaticity

  • Measure strobe ratios (foreground/background or main/fill/hair, etc.)
  • Simultaneously measure color of different light sources, e.g. daylight from windows and artificial lighting

RGB Status Indicator LEDs on Meter Face

  • Used for displaying status information – battery warning, BLE connection status, etc
  • Primarily used to display user-programmable light and color level alarms. The LEDs are a great way to check lighting conditions with even looking at your phone.

Powered by two AAA batteries

  • Battery life is approximately 40 hours of continuous use
  • AAA batteries are easy to find and easy to replace
  • No need to worry about charging an internal or proprietary battery

Spring-loaded Retractable Dome

  • The dome toggles up/down much like a ballpoint pen cap
  • Raise the dome for metering people or other 3D objects and multiple light sources at the same time
  • Retract the dome for metering flat objects or single light sources
  • Safety feature: accidental pressure on the dome will push it into meter body instead of cracking
